HTTF-1200-VHP Vacuum Heated Pressing Furnace is designed for making dense compound materials under both vacuum and high pressure up to 2 metric tons. This hot pressing furnace is integrated with a split vertical tube furnace with a vacuum-sealed 4" quartz tube and 2000Kg digital electric press, as well as one set of 0.5" ID graphite pressing, die. The hot press tube furnace can be heated up to 1000ºC.
Pledge: genuine guarantee,speed refund,gift insurance,seven days no reason to return
HTTF-1200-VHP Vacuum Heated Pressing Furnace is designed for making dense compound materials under both vacuum and high pressure up to 2 metric tons. This hot pressing furnace is integrated with a split vertical tube furnace with a vacuum-sealed 4" quartz tube and 2000Kg digital electric press, as well as one set of 0.5" ID graphite pressing, die. The hot press tube furnace can be heated up to 1000ºC using a temperature controller with 30 programmable segments. Water-cooled flanges facilitate a vacuum level up to 10E^-5 Torr via the use of an optional turbo molecular pump.
Note: Chang hydraulic press into more precision digital electric press since March 25, 2020
Max. Pressure | 2 metric tons ( 50 Mpa on 0.5" ID graphite ) limited by supporting structure |
Digital Electric Press | Built-in a digital electric press with Max. load capability of 2 metric tons on the bottom of the furnace Pressure adjustment range: 0.1-2 T adjustable with constant pressure function Travel distance： 20 mm Pressure accuracy: +/- 0.003T Time setting: 1 - 999 minutes |
Vertical Furnace | Splittable vertical furnace heated by Ni-Cr-Al resistance wire Max. working Temp> 1000oc < 60 minutes Max. Heating Rate: < 10oC/minute 30 segment programmable controller with +/-1ºC accuracy RS485 port installed for remote PC operation Power consumption: 2200W Power input: 208 - 240VAC, 50/60 Hz single phase Note: HT reserves the right to update the product with better functions without notice. |
Heating Zone | Heating Zone Length: 12" (300mm) Constant temperature zone: 100mm |
Quartz Tube & Sealing Flange | One quartz tube 100 OD x 94 ID x 640L mm (4" x 25") is included Water-cooled flanges are installed on two ends of the tube with a KF-25D vacuum port & pressure gauge as well as a 1/4" gas inlet port with an SS304 needle valve >12L/minute water flow is required, and using an optional recirculating water chiller to save water is highly recommended. |
Option Vacuum Pump | Max. achievable vacuum level: 10E^-4 Torr by turbo pumping station (turbo pumping system with powerful backing pump, please don't use small pumps) Or 10^-2 torr by a mechanical pump. Please click on the left to choose a vacuum pump at extra cost. |
Graphite Pressing Die Set | One set graphite supporting rod (One top & one bottom) is built-in. One set of 0.5" ID graphite die is included for immediate use. The dies are made of high purity graphite with a working pressure of 50 MPa, under 600Kg force The graphite pressing die gets broken easily and is consumable, please click on the central photo below to order extra sets. We can also provide customized die sets upon customer request at extra cost Mica spacers are used to adjust the height of die sets (while providing heat insulation). Please click on the bottom right picture below to order spares.（bottom right photo） |
Dimensions | L750 × W800 × H1850mm ( please click the picture below to see details ) |
Net Weight | 365 kg |
Weight of Shipment | 450 kg |
Warranty | The pressing machine was quality inspected in the USA, lifetime support is provided One-year limited standard warranty, (Consumable parts like graphite die do not have any warranty.) (Extended warranty is available for up to 5 years at extra cost) |
Application Notes | Attention: A two-stage pressure regulator must be installed on the gas cylinder to limit the pressure to below 3 PSI for safe operation. |
